XF 卧式沸腾干燥机

XF 沸腾干燥机
XF SERIES FLUID-BED DRYER
用途概述General of
它适用于粉粒状物料的干燥,如:医药药品中的原料药,压片颗粒药、中药冲剂、化工原料中的塑料树脂、柠檬酸和粉状、颗粒状物料的干燥除湿,还用于食品饮料冲剂,粮食加工、玉米胚芽、饲料等的干燥。物料的粒径一般为大可达6 mm ,*为 0.5-3mm 。
IIt is suitable for drying powder and granule material such as raw material in pharmaceutical industry, granule material for pressing tablet, infusion of Chinese medicine; in chemical industry, drying and damp removing of citric acid, other powder and granule shape materials. It can also be suitable for food, drinking infusion, etc; in grain process, drying maize embryo, feedstuff and so on. In general the maximum size of material may reach 6 mm. The best is 0.5 ~ 3 mm
XF 沸腾干燥机技术参数:Technical Data
型号
Specification
蒸发能力
(水)
( Kg/h) vaporize capacity
风机功率
( Kw )
Power of fan
风压 pressure of fan
( Mpa)

风量 quantum of wind
( m 3 /h)

进风温度
(℃) T of air inlet

蒸气耗量
Steam consume
(kg/h)
外形尺寸 (m) Overall dimensions
Габариты
A 型
B 型
C 型
XF-10
10--15
7.5
5.5
1500
60-200
50
4X3.5X3.2
3.5X3.5X3
5X3.5X3.5
XF-20
20--25
7.5
5.8
2000
60-200
80
4.5X4X4.2
4X4X3.2
6X4X4.5
XF-30
30--40
15
7.1
3850
60-200
150
5X4X4.8
4X4X4.2
6X4X5
XF-50
50--80
30
8.5
7000
60-200
250
5X4.8X5
5X4.8X4.5
6X4.8X5
所有参数仅作参考 , 视物料情况 , 本公司拥有变更权利 , 并不另行通知 .
*All datas are used for reference only. According to the condition of material, our factory has the right change but not notice, pardon!
